Page 90 - ITC 2024 EN

PETROL ENGINE PUMPS
HIGH PRESSURE

GPH50

PETROL ENGINE PUMP
CLEAN
WATER
HIGH
PRESSURE
50 MM
2”

500 L / MIN

65 M

9 MM

210 CC

PETROL

30 KG

OPTIONAL:

CONSUMABLES ACCESSORIES
•4-stroke OHV engines with oil alarm.
•High quality mechanical seal. FOOT VALVE NON-
•Light and compact construction. RETURN WITH
•Aluminium injection pump body. MOTUL OIL CONNECTION
•Ø 32 mm chassis. 4T 15W40 40 MM (1 ½“)
•Including connection fittings and particle filter. 2 L / MT-101311 50 MM (2”)
5 L / MT-101312
80 MM (3”)
100 MM (4”)
OIL EXTRACTOR
KIT
HY-OILEX16

MODEL GPH50 ACCESSORIES INCLUDED:
Suction/impeller diameter 50 mm (2’’)
Maximum flow rate 30 m /h (500 L/min)
3
Maximum height / Pressure 65 m / 6,5 Bar
Solid particle diameter 9 mm
Engine model IC210
Engine type OHV
Displacement 208 cc
Starting system Manual
Revolutions 3.600 rpm
Engine power 7,0 HP
Fuel capacity 3,6 L
Dimensions 53 x 42,5 x 43 cm
Net weight 30 Kg
EAN 06140701081015

90
