Page 46 - ITC 2024 EN
P. 46
DIESEL GENERATORS
OPEN DIESEL GENERATOR
NEW
DG10000LEK-T
DIESEL GENERATORS
SINGLE AND
THREE PHASE
7,2 KW /10KVA
7,6 KW / 10,6 KVA
DIESEL
72 DBA
225 KG
OPTIONAL:
CONSUMABLES
MOTUL OIL
4T 15W40
2 L / MT-101311
5 L / MT-101312
OIL EXTRACTOR
KIT
HY-OILEX16
NEW
1 X 1 X 16A AVR LED6
32A PCE 5P
MODEL DG10000LEK-T
RATED POWER 10 KVA (400V) / 7,2 Kw (230V) BATTERY 36 Ah
MAXIMUM POWER 10,6 KVA (400V) / 7,6 Kw (230V) OIL CAPACITY 2,4 L
FREQUENCY 50 Hz OIL ALARM Yes
VOLTAGE ALTERNATOR AL8
Full Power 400 V / 230 V
INTENSITY 31A/ 14,4 TYPE
AC OUTPUTS 1 x 16 A /1 x 32 A POWER 8000 W
DC OUTPUT 12V / 8,3A POWER FACTOR 1
DIGITAL DISPLAY LED6 VOLTAGE REGULATION AVR / Brushes
OVERLOAD PROTECTION Yes LOGISTICS
TANK CAPACITY 11 L NET WEIGHT 132 Kg
AUTONOMY 5 H GROSS WEIGHT 136 Kg
ACOUSTIC PRESSURE AT 7M 79 dBA PRODUCT DIMENSIONS 740 x 550 x 655 mm
SOUND LEVEL BOX DIMENSIONS 760 x 560 x 670 mm
ENGINE DIESEL D680E EAN 641022889459
ENGINE POWER 14,4 HP
DISPLACEMENT 678 cc
STARTING SYSTEM Electric / ATS
46
