Page 56 - ITC 2024 EN

DIESEL GENERATOR
SOUNDPROOF DIESEL GENERATOR

NEW

DG15000SE
DIESEL GENERATOR

SINGLE-PHASE
11 KW
12 KW
DIESEL

72 DBA

295 KG

OPTIONAL:

CONSUMER PRODUCTS

MOTUL OIL
4T 15W40
2 L / MT-101311
5 L / MT-101312

OIL EXTRACTOR
HY-OILEX16
NEW

MODEL DG15000SE
POWER NOM. 11 Kw BATTERY 12/45 V/Ah
POWER MAX. 12 Kw OIL CAPACITY 2,8 L
FREQUENCY 50 Hz OIL ALARM -
VOLTAGE 230 V ALTERNATOR AL12
CURRENT 52,2 TYPE -
AC OUTPUTS 1xPCE 5p 50A + 1x32A +1x16A POWER 12 Kw
DC OUTPUT NO POWER FACTOR 1
DIGITAL DISPLAY LED VOLTAGE REGULATION AVR / Brushes
OVERLOAD PROTECTION - LOGISTICS
TANK CAPACITY 25 L NET WEIGHT 295 Kg
AUTONOMY 75% LOAD 8 H GROSS WEIGHT 315 Kg
SOUND PRESSURE AT 7M 72 dBA PRODUCT DIMENSIONS 1300 x 650 x 760 mm
SOUND POWER BOX DIMENSIONS 1350 x 700 x 880 mm
MOTOR DIÉSEL D1000E
ENGINE POWER 19 HP
CYLINDER 997 cc
START Electric

56
