3 CYLINDERS 4 CYLINDERS
MODELS DG11K(S)E DG14K(S)E DG16K(S)E DG22K(S)E DG34K(S)E
Three Phase Three Phase Three Phase Three Phase Three Phase
Frequency (Hz) 50 50 50 50 50
Rotational speed (r/min) 1.500 1.500 1.500 1.500 1.500
Power factor 0,8 0,8 0,8 0,8 0,8
CHARACTERISTICS Emergency power (kW) 11 14 16,5 22 34,4
10/8
15/12
31,3/25
12,5/10
20/16
Rated power (kW)
14,4
29
18
Rated current (A)
45
21,6
Sound level (7m, 75% load) (dBA)
65
66
66
65
66
12
15,4
Autonomy at 100%
17
12
10
Consumption at 100% load (L/horas)
6
10,2
6
12
Radiator coolant capacity (L) 3,5 4,5 5 7 6,3 9,5
Standard tank capacity (L) 42 46 78 78 93
Engine model D4DX21-53D D390 D485 D490 D4102
Rated power at 1.500 rpm (kW) 11 14 17 21 32
ENGINE Number of cylinders 3 Natural 3 4 Natural 4 4
Intake
Natural
Natural
Natural
Oil sump capacity (L) 4,5 5 6 6,5 10,2
Displacement (cc) 1.360 1.360 2.200 2.500 3.800
ALTER. Model 164B 164C 164D 184E 184G
IP23/H
IP23/H
IP23/H
Degree of protection
IP23/H
IP23/H
PACKAGING Weight open version (Kg) 365 435 490 505 690
480
786
760
980
520
Weight soundproof version (Kg)
180x95x101
Open version dimensions (cm)
125x80x95
125x80x95
156x90x98
156x90x98
220x95x123
163x78x110
190x90x110
190x90x110
Soundproof version dimensions (cm)
150x76x107
